Kawuku Lakeside · Kampala · SUG-BD-KAWUKU-001

The Future
Lives Here.

A complete 4-phase smart technology infrastructure for 50 premium lakeside residences in Kawuku. Dedicated 10G fibre to every home. World-class on-site data centre. AI-powered security. Power as a Service.

Site
Kawuku, Kampala
Area
7 Acres · Lakeside
Homes
50 Premium Residences
Phase 1
30 Working Days
Explore All Phases View Live Demos
SUG-BD-KAWUKU-001 · CONFIDENTIAL
Kawuku Smart Infrastructure
10G
Per Home
120
Manholes
116
Cameras
1
Core Optical Network
30 working days · 10G P2P per home
2
Security & Data Centre
116 cameras · Tier-II DC · Smart access
3
SprintUG Smart BMS
Custom platform · SmartLiving App
4
Power as a Service
Pay per use · SprintUG-owned infra
0
Premium Homes
10G
Per-Home Fibre
0
Underground Manholes
0
IP Cameras
Tier II
On-Site Data Centre
Our Approach

Vision for Kawuku Smart Residences

SprintUG will design, install, and operate every digital touchpoint of the Kawuku estate. From the moment a resident opens their door with a fingerprint, to the 10G connection that never buffers, to the real-time energy bill in their pocket — every interaction will be engineered to the highest standard.

The complete stack: 120-manhole underground fibre network, 116 AI-enabled IP cameras, smart locks and intercoms at every home, a purpose-built Tier-II Data Centre, a custom SprintUG Building Management System, and a pay-per-use power model — all owned and operated by SprintUG permanently.

bolt
Real-Time Everything
Live energy dashboards, instant security alerts, per-port network monitoring — all processed on-site in the Kawuku Data Centre. Zero cloud dependency.
link
Single Integrated Platform
All four phases run over one network with VLAN segmentation. One operations team, one SLA, one point of contact. Built and owned by SprintUG.
smartphone
Resident-First Design
The SprintUG SmartLiving App puts full home control — lock, energy, visitor, alarm — in the resident's hand from anywhere in the world.
The SprintUG Commitment
This is not a handover-and-leave project. SprintUG installs, owns, and operates permanently — monitoring every device, every connection, every watt consumed, every door that opens. We are the estate's technology partner, not a contractor.
Infrastructure Guarantees
Dedicated 10G symmetric — zero contention, zero sharing at every home
IP68-sealed precast manholes engineered for lakeside groundwater
Ring topology · automatic failover in under 50 ms on any fibre break
Tier-II Data Centre on-site — estate runs autonomously without internet
99.5% power availability SLA per home under PaaS model
24/7 SprintUG NOC — all alarms auto-ticketed, SLA-driven escalation
Connectivity
Fibre, network, data infrastructure
Security
CCTV, access control, Data Centre
Intelligence
BMS, SmartLiving App, analytics
Complete Infrastructure Stack

Four Phases. One Vision.

Four integrated phases that build on each other to deliver a complete smart estate. Click any phase to jump to full technical detail.

public
Phase 1 — Core Optical Network
The permanent nervous system. OS2 single-mode fibre, 120 underground manholes, dedicated P2P 10G to every home.
120 precast concrete manholes · IP68 sealed
Backbone ring with <50 ms failover
10GBASE-LR SFP+ at every home
View Phase Detail →
lock
Phase 2 — Security & Data Centre
116 AI cameras, smart locks and intercoms at every home, ANPR gates, 4 guard stations — running from a Tier-II on-site Data Centre.
116 IP cameras · AI analytics · 30-day NVR
SIP video intercom at every residence
FM-200 · 40kVA UPS · 60kVA generator
View Phase Detail →
psychology
Phase 3 — SprintUG Smart BMS
A custom-built Building Management System. Energy, security, environment, SmartLiving App, assets, analytics — all one platform.
Custom SprintUG platform — no third-party tools
SmartLiving App · iOS & Android
BACnet · Modbus · MQTT · ONVIF · Zigbee
View Phase Detail →
bolt
Phase 4 — Power as a Service
SprintUG installs and owns all low-voltage power infrastructure. Residents pay only for what they use. Zero capital for developer.
MDB → Sub-DB → HDB · SprintUG-owned
Class 1 smart meters · 15-min interval billing
MTN / Airtel / M-Pesa / VISA payment
View Phase Detail →
smartphone
SprintUG SmartLiving App
The resident-facing mobile platform. One app to control the home, manage visitors, monitor energy, book amenities, and call for help.
Remote door lock/unlock from anywhere
Gate visitor pre-authorisation
Panic button · energy bill · community board
View in Demo →
bar_chart
Custom Dashboards & NOC
All monitoring through SprintUG-built custom dashboards. Per-port visibility, CCTV console, energy heatmaps — purpose-built. No third-party tools.
SprintUG custom monitoring UI
24/7 NOC · auto-ticket escalation
Monthly estate health report · board-ready PDF
View in Demo →
Phase 01 · Core Infrastructure

Underground Fibre Network

120 precast concrete manholes buried across 7 acres. OS2 backbone ring with dedicated home-run drops. A 10 Gigabit port at every residence — symmetric, non-shared, non-contended.

P2P Active Ethernet — Zero Sharing
Star topology from two Distribution Points to each home. Every home gets its own dedicated fibre strand and 10G switch port. Ring backbone provides <50ms failover.
10GBASE-LR · SC/APC · OS2 G.652.D
120 Sealed Manholes · IP68 Rated
90× inline (900×600×800mm) and 30× junction (1200×900×1000mm) precast concrete. Bituminous mastic sealed, D400 traffic-rated lids, all cables labelled throughout.
IP68 · D400 traffic-rated · lakeside sealed base
12-Core Drop · 10 Dark Cores Reserved
2 cores active for 10G service, 10 cores dark and available for future services. G.657.A2 bend-insensitive for tight-radius runs inside homes.
G.657.A2 · <2.5dB end-to-end · Wi-Fi 6E CPE
30 Working Days — 5-Week Schedule
W1: Survey. W2: Backbone trenching. W3: Fibre pull & splicing. W4: Home drops & HTP. W5: Active equipment, OTDR acceptance, handover.
OTDR baseline · iPerf3 ≥9.4 Gbps per home
NOC · Kawuku Fibre Network
PHASE 1 — FIBRE NETWORK
LIVE
50
Ports Online
120
Manholes
10G
Per Home
0
Faults
Network Utilisation — All 50 Homes (Gbps)
CER Core Stack
100% ● Healthy
Ring Protection
Active ● <50ms
VLANNamePurposeType
10MGMTOOB management — switches, UPSINFRA
20CCTV116 cameras → NVR (no internet)SECURITY
100–149HOME_nDedicated VLAN per residenceHOME
250IOTSmart home sensors · ZigbeeHOME
300POWERSmart meters (Phase 4)POWER
Phase 02 · Security

360° Smart Security & Data Centre

Every camera, lock, doorbell, and intercom on the fibre backbone. All data into the on-site Tier-II Data Centre that keeps the estate running with or without internet.

116 IP Cameras — AI-Enabled
Full perimeter, roads, common areas, per-home driveways. AI analytics: perimeter crossing, loitering, vehicle detection, ANPR at gates. 30-day NVR on-site.
4MP varifocal · H.265+ · ONVIF · 30-day storage
Smart Access at Every Home
Fingerprint + PIN + RFID + app smart lock. 4MP video doorbell. 7-inch SIP touchscreen indoor intercom. PIR + window sensors on all ground-floor openings.
OSDP v2 · SIP · Zigbee · 110dB alarm
Tier-II On-Site Data Centre
48 m² server facility. FM-200 fire suppression, 40kVA UPS 8-hour runtime, 60kVA diesel generator, N+1 precision cooling, biometric triple-auth, 6× 42U racks.
FM-200 · 40kVA UPS · auto-gen <15s ATS
4 Guard Monitoring Stations
Main gate, perimeter, inner patrol, DC. Each with CCTV wall display, SIP console, dispatch terminal, ANPR feed. IP PA broadcast across estate.
SIP · PA broadcast · ANPR · one-click dispatch
Phase 03 · Building Management

SprintUG Smart BMS

A custom platform built entirely by SprintUG. Six modules: energy, security, environment, SmartLiving App, asset management, and analytics. Hosted in the on-site Data Centre — zero cloud dependency.

Energy Management Module
Real-time per-home kWh dashboards on custom SprintUG UI. Anomaly detection, solar net-metering, peak/off-peak load scheduling.
Modbus TCP · BACnet/IP · 15-min interval data
Security Console Module
Unified alarm wall for all 50 homes. Auto camera popup on alarm. One-click guard dispatch. Auto-generate tamper-proof PDF incident reports.
ONVIF · OSDP v2 · SIP Asterisk integration
SmartLiving App Module
iOS/Android resident app. Remote door control, visitor gate management, energy bill, panic button, amenity booking, community announcements.
React Native · REST API · WebSocket live
Predictive Maintenance Module
ML model trained on device sensor history. Flags switches, UPS batteries, HVAC units at elevated failure risk before they fail. Auto work orders.
TensorFlow Lite · Asset register · Work orders
Dashboard
App
bms.kawuku.sprintug.com
LIVE
kWh Today
847
↓ 12% vs last month
Active Alarms
2
Motion · Home 23, 41
Homes Online
50/50
All ports active
24h Energy Profile — Estate Total
Network
100% ● All OK
Generator
STBY ● Fuel 84%
Phase 04 · Power Infrastructure

Power as a Service

SprintUG installs and owns all low-voltage distribution — MDB to home board. Residents pay only for what they consume. Zero capital for the developer.

MDB → Sub-DB → HDB Full Hierarchy
800A Main Distribution Board at DC. Two 400A sub-distribution kiosks (North/South, 25 homes each). Dedicated 63A circuit to every home. All SprintUG-owned.
Class I/II/III SPD · ATS <5s · 60kVA generator
Class 1 Smart Meters · 15-Min Data
Bi-directional IEC 62053-21 smart meters on every home. 15-minute interval data to BMS. Real-time app visibility. Monthly bill by mobile money or card.
IEC 62053-21 · Modbus TCP · MTN/Airtel/M-Pesa
Solar & EV Ready — Day One
4-quadrant net-metering pre-installed for rooftop solar. Dedicated 32A Type 2 EV charging circuit in every garage, activated on request — zero retrofitting.
Solar net-metering · EV Type 2 · Battery storage
99.5% Availability SLA
SprintUG maintains all equipment. 4-hour fault response 24/7. Meter replaced within 24 hours. Service credit issued for any breach. Pre-pay and post-pay available.
24/7 response · SLA credits · pre/post-pay
power.kawuku.sprintug.com
Live Meter · Home 24
3.41 kW
This Month
847 kWh
↓ 8% vs last month
UGX 142K
Est. Bill
84%
Credit
+12kWh
Solar Export
MAINS
Source
PaaS vs. Traditional Model
TraditionalDeveloper pays all wiring & meters
SprintUG PaaSZero capital for developer
TraditionalOpaque utility bill, no visibility
SprintUG PaaSReal-time app · transparent per-unit rate
TraditionalHomeowner maintains equipment
SprintUG PaaSSprintUG owns & maintains everything
Project Roadmap

Implementation Timeline

Each phase follows SprintUG's pilot-checklist methodology — no assumptions, every step verified before proceeding.

1
Phase 1
Core Optical Network
30 Working Days
  • Site survey & full peg-out
  • 120 manholes installed & sealed
  • OS2 fibre backbone ring
  • Home drops & HTP installation
  • Active equipment & OTDR handover
2
Phase 2
Security & Data Centre
Following Phase 1
  • DC fit-out & commissioning
  • 116 cameras installed
  • NVR, AI analytics, storage
  • Smart locks, doorbells, intercoms
  • Guard stations & ANPR gates
3
Phase 3
SprintUG Smart BMS
Concurrent / Post P2
  • BMS server cluster deploy
  • Device onboarding & integration
  • SmartLiving App release
  • Resident onboarding
  • Custom dashboards go-live
4
Phase 4
Power as a Service
Ongoing · Recurring
  • MDB & sub-DB installation
  • Per-home distribution boards
  • Smart meter commissioning
  • Billing engine go-live
  • Solar & EV infrastructure ready
Phase 02 · Security & Data Centre

World-Class Phase 2 Design

Visualised execution of CCTV, access control, intercom, BMS and fibre infrastructure for Kawuku. This section shows complete scope including diagrams, KPIs, and failover strategy.

Full Phase 2 Summary: 116 cameras, 8 NVRs, AI analytics, smart locking, ANPR gate with vehicle queue management, dual-path fibre ring, Tier III data centre, and 100% NOC monitoring.

Command
Centralized Command
On-site NOC in clubhouse, 24/7 staffing, redundancy in separate shelter, automatic failover to secure cloud circuit.
Fibre
Fibre Redundancy
Dual fibre routes (north/south), protected conduit, blowable microduct for future expansion, 10G edge switches with 1:1 lane backup.
Security
Access Control
Biometric turnstiles + mobile credential, guardhouse integration, lock-down mode from BMS, visitor QR issuance via intercom endpoint.
Comm
Intercom & Communications
Intercom across gates, towers, and villas with VoIP routing to security and concierge, plus app push alerts and SMS fallback.
BMS
BMS Integration
BACnet over IP with third-party HVAC and lighting; Energy usage snapshots in 5-minute intervals; programmable rules for occupancy-aware lighting and chilled water.
CCTV
CCTV + AI Analytics
Edge AI analytics for intrusion detection, loitering, ANPR, and crown-of-head detection; 90-day rolling storage with GDPR-level encryption.
All diagrams are secure; download is disabled in public demo mode.
Why SprintUG Wins This

Built Different.
Delivered Complete.

Every other ISP or integrator draws a line. We don't. End-to-end ownership from fibre in the ground to watts on the meter.

0
Homes · Full Coverage
10G
Dedicated Per Home
PaaS
Revenue Model
24/7
NOC Monitoring
End-to-End Ownership
From fibre conduit in the ground to smart meter on the wall. SprintUG designs, installs, owns, and operates everything. No third parties. No gaps. No excuses.
Autonomous On-Site DC
When the internet goes down, Kawuku keeps running. CCTV records. Locks work. BMS manages. The Data Centre is the estate's brain — always on, always on-site.
Pilot's Methodology
David Emiru Egwell, CPL and CTO, runs infrastructure delivery the way a pilot runs pre-flight. Checklists. No assumptions. Every step verified before proceeding.
Ready to Build

Let's Build Something Extraordinary

SprintUG is ready to transform Kawuku Lakeside Residences into the most intelligently connected estate in Uganda. Phase 1 can begin within days of engagement.

Schedule a Presentation View Full Proposal

What Happens Next

From first call to Phase 1 go-ahead in three steps.

1
Discovery & Site Walk
A 60-minute on-site walk with David Emiru Egwell, CTO, to review the site, confirm Phase 1 scope, and align on the 30-day delivery schedule.
2
Technical Proposal Confirmation
Customised Bill of Materials and Engineering Schedule for Phase 1, with indicative investment for all four phases and the PaaS monthly fee structure.
3
Phase 1 Mobilisation
Site survey finalised, civil contractor briefed, materials delivered — Phase 1 trenching begins. The clock starts on 30 working days.
Get In Touch
Chief Technology Officer
David Emiru Egwell
Company
SprintUG Internet Limited
Operations
Uganda · Tanzania · South Africa
End-to-end ownership — fibre to smart meter, SprintUG owns it all
17-engineer team; capability assessment complete and delivery-ready
Proven ISP infrastructure across Uganda and Tanzania
Custom BMS — no third-party software dependency whatsoever
PaaS creates recurring revenue for SprintUG; zero capex for developer
30-day Phase 1 on a published, verified delivery schedule
